SNM-1001L Satellite Modem
Revision 1
Front Panel Operation
MN/SNM1001L.IOM
4–19
FUNCTION SELECT: CONFIGURATION: DEMODULATOR:
RX-IF FREQUENCY (CONDITIONAL)
RX-IF FREQUENCY
1200.0000 MHz
IMPORTANT
Conditional: This menu is displayed when LO is programmed to 0
under Utility: Demodulator: RX Terminal LO menu.
Programs the demodulator receive frequency between 950 and 1750 MHz,
in 100 Hz steps.
Upon entry, the current receive frequency is displayed with the flashing cursor on the first
character. Press [
←] or [→] to move the flashing cursor, and [↑] or [↓] to increment or decrement
the digit at the flashing cursor. Press
FUNCTION SELECT: CONFIGURATION: DEMODULATOR:
RX TERMINAL FREQUENCY (CONDITIONAL)
RX TERMINAL FREQUENCY
4200.0000 MHz
IMPORTANT
Conditional: This menu is available only when RX Terminal LO and Mix
are programmed under Utility: Demodulator menu.
The reminder of the functions is the same as RX-IF Frequency.
Note: This permits programming of the RX frequency of the satellite terminal, including the
modem and LNB. When properly setup it indicates the satellite frequency of the desired RX
carrier received from the satellite.
