Comtech EF Data SNM-1001L - Manual (Page 280)

SNM-1001L Satellite Modem Revision 1
Remote Control Operation MN/SNM1001L.IOM
B–6
Set
Modulator
Power
Offset Command:
Response:
Status:
Response: >add/MPO_snn.n’cr’’lf’]
>add/MPO_snn.n’cr’’lf’]
Where: snn.n = +99.0 to –99.0, in 0.1 dB increments.
Note: The modulator power offset is added to the nominal
power level to adjust the transmit power range.
Set
Modulator
Output
Power Level Command:
Response:
Status:
Response: >add/MOP_snn.n’cr’’lf’]
>add/MOP_snn.n’cr’’lf’]
Where: snn.n = -30.0 to –5.0, in 0.1 steps (nominal range
in dBm) for the non TX L-Band modem and –40.0 to 0.0,
in 0.1 steps for the TX L-Band modem.
Notes:
1. The nominal power range is modified relative to
the value specified by the modulator power offset
(MPO_).
2. The MOP_ command will return status only when
local AUPC is enabled.
Scrambler
Enable Command:
Response:
Status:
Response: >add/SE_xxx’cr’’lf’]
>add/SE_xxx’cr’’lf’]
Where: xxx = ON or OFF.
Differential
Encoder
Enable Command:
Response:
Status:
Response: >add/DENC_xxx’cr’’lf’]
>add/DENC_xxx’cr’’lf’] Where: xxx = ON or OFF.
Modulator
Type Command:
Response:
Status:
Response: >add/MT_xxxx’cr’’lf’]
>add/MT_xxxx’cr’’lf’]
Where: xxxx = INTL (INTELSAT OPEN NETWORK), EFD
(EF DATA CLOSED NETWORK), CSC (COMSTREAM
CLOSED NETWORK), FDC (FAIRCHILD CLOSED
NETWORK), SDM51 (SDM51 COMPATIBLE).
Modulator
Encoder
Type Command:
Response:
Status:
Response: >add/MET_xxx’cr’’lf’]
>add/MET_xxx’cr’’lf’]
Where: xxx = VIT (K-7 VITERBI ENCODER), SEQ
(SEQUENTIAL ENCODER) or TUR (TURBO).
Modem
Reference
Clock Command:
Response:
Status:
Response: >add/MRC_xxxxx’cr’’lf’]
>add/MRC_xxxxx’cr’’lf’]
Where: xxxxx = INT (INTERNAL), EXT1 (EXTERNAL 1
MHz), EXT5 (EXTERNAL 5 MHz), EXT10 (EXTERNAL 10
MHz), EXT20 (EXTERNAL 20 MHz), OUT10 (OUTPUT
10 MHz).
Modulator
Spectrum
Rotation Command:
Response:
Status:
Response: >add/MSR_xxx’cr’’lf’]
>add/MSR_xxx’cr’’lf’]
Where: xxx = NRM (normal spectrum), INV (inverted
spectrum).
Reed-
Solomon
Encoder
Enable Command:
Response:
Status:
Response: >add/RSEN_xxx’cr’’lf’]
>add/RSEN_xxx’cr’’lf’] Where: xxx = ON or OFF.
Transmit
BPSK Data
Ordering Command:
Response:
Status:
Response: >add/TDA_xxx’cr’’lf’]
>add/TDA_xxx’cr’’lf’] Where: xxx = NRM (STANDARD), INV (NON-
STANDARD).
Carrier Only
Mode Command:
Response:
Status:
Response: >add/COM_xxxxxx’cr’’lf’]
>add/COM_xxxxxx’cr’’lf’] Where: xxxxxx = OFF (NORMAL-MODULATED), DUAL
(DUAL-CW), OFFSET (OFFSET-CW), CENTER
(CENTER-CW).
Reed-
Solomon
Interleave
Value Command:
Response:
Status:
Response: >add/TRSI_xx’cr’’lf’]
>add/TRSI_xx’cr’’lf’] Where: xx = 4, 8, or 16.
