SNM-1001L Satellite Modem Revision 1
Front Panel Operation MN/SNM1001L.IOM
4–42
FUNCTION SELECT: MONITOR: ODU CURRENT
ODU CURRENT
XXXX mA
Monitors the ODU current or “ODU POWER OFF.”
Current displayed is 0 to 5000 mA in 1 mA increments.
FUNCTION SELECT: MONITOR: ODU VOLTAGE
ODU VOLTAGE
XX.X VOLTS
Monitors the ODU voltage or “ODU POWER OFF.”
Voltage displayed is 0 to 64 volts, in 0.1 volt increments.
FUNCTION SELECT: MONITOR: ODU OUTPUT LEVEL (CONDITIONAL)
ODU OUTPUT LEVEL
xx.xx dBm
IMPORTANT
Conditional: This menu is displayed when the FSK and ODU POWER
SUPPLY are On under the Configuration: Modulator menu.
Displays ODU output power as reported by an FSK capable BUC.
