SNM-1001L Satellite Modem Revision 1
Front Panel Operation MN/SNM1001L.IOM
4–72
FUNCTION SELECT: UTILITY: DEMODULATOR: MAX PACKET SIZE
MAX PACKET SIZE
2048 BITS
Maximum Packet Size: 0 to 1048567 bits.
FUNCTION SELECT: UTILITY: DEMODULATOR: DEMOD SPECTRUM
DEMOD SPECTRUM
NORMAL
Programmable vector rotation. Select Normal or Inverted for spectrum reversal of the I and Q
baseband channels.
FUNCTION SELECT: UTILITY: DEMODULATOR:
RX-RS N/K DEEP (CONDITIONAL)
RX-RS N/K DEEP
225/205 8
IMPORTANT
Conditional: This menu is active only when Reed-Solomon (RS) is
installed and RS Option is On (under Configuration: Demodulator).
N/K is status only.
Deep is interleaver depth and is programmable to a depth of 4, 8, or 16.
