SNM-1001L Satellite Modem Revision 1
Front Panel Operation MN/SNM1001L.IOM
4–86
FUNCTION SELECT: UTILITY: MODEM TYPE: MODEM OPTIONS
MODEM OPTIONS
-+ + - + - - - + + + + + - - +
Status Only.
Displays the installed modem options.
If the option is installed, a “+” symbol is displayed. To view the available options press
. Observe for the flashing cursor. Press the [
←] [→] arrows to move from one symbol
to the next. The first line will display the option. The second line will display the status:
Option Code Legend
HIGH POWER (see Note)
HIGH STABILITY
ASLT
VITERBI
SEQUENTIAL
SINGLE RATE
LOW RATE VAR
FULL RATE VAR
CARD #1 PCB
CARD #2 PCB
CARD #3 PCB
8-PSK
TX only
RX only
OQPSK
TX/RF L-BAND (0 or +)
(0 or +)
(- or +)
(- or +)
(- or +)
(- or +)
(- or +)
(- or +)
(x or +)
(x or +)
(x or +)
(- or +)
(0 or +)
(0 or +)
(- or +)
(0 or +) 0 = Not Installed, Not Upgradeable
- = Not Installed, FAST Upgradeable
+ = Installed
x = Not Installed, Field Upgradeable
IMPORTANT
The actual choices displayed in the sub-menus may vary according to
which FAST options have been enabled. Where a FAST option affects a
menu, this is shown in the descriptive text.
Note: There are no power options for the L-Band modem.
