SNM-1001L Satellite Modem Revision 1
Remote Control Operation MN/SNM1001L.IOM
B–16
Notes:
1. Data is only returned for TX D&I Overhead (or Flex Mux
D&I).
2. Data is only returned for TX IDR Overhead.
2. Data is only returned for TX ASYNC Overhead
3. Data not returned if Local AUPC is enabled & TX
ASYNC/AUPC overhead.
5. Not Used.
6. Not Used.
7. Not Used.
8. Not Used.
9. Not Used.
Current
Transmit
Reed
Solomon N/
K and
Interleaver
value Command:
Response: >add/TXRS_nnn/kkk_ii'cr''lf'] Where: nnn = N value, kkk = K value and ii = Interleaver value.
Scrambler
Type Command:
Response: >add/SCR_xxxxxxxxxxxx’cr’’lf'] Where xxxxxxxxxxxx = EFD MOD V.35, INTELSAT V.35, FDC
MOD V.35, ITU V.35 or OFF.
B.4.2 Demodulator Configuration Status
Demodulator
Config.
Status Command:
Response:
>add/DCS_'cr'
DF_nnnnn.nnnn'cr'
DR_nnnn_mmmm.mmm'cr'
ADRA_nnnn_mmmm.mmm'cr'
ADRB_nnnn_mmmm.mmm'cr'
ADRC_nnnn_mmmm.mmm'cr'
ADRD_nnnn_mmmm.mmm'cr'
ADRV_nnnn_mmmm.mmm'cr'
DE_xxx'cr'
DDEC_xxx'cr'
IFL_xxx’cr’ (Note
1)
SCF_snnnnn'cr'
SWR_nnnnnn'cr'
SR_xxx'cr'
ERT_xxxx'cr'
DT_xxxx'cr'
DDT_xxx'cr'
DSR_xxx'cr'
RSDE_xxx'cr'
RDA_xxx'cr'
RRSI_xx'cr'
R310_xxx'cr'
LNB_xxx’cr’
LNBV_xxx’cr’
LNBR_xxx’cr’
LNBL_xxx’cr’
LNBH_xxx’cr’’lf’]
Demodulator Frequency
Demodulator Rate
Preset 'A' Assignment
Preset 'B' Assignment
Preset 'C' Assignment
Preset 'D' Assignment
Preset 'V' Assignment
Descrambler Enable
Differential Decoder
IF Loopback
Sweep Center Frequency
Sweep Width Range
Sweep Reacquisition
BER Threshold
Demodulator Type
Demodulator Decoder Type
Demodulator Spectrum Rotation
Reed-Solomon Decoder
Receive BPSK Data Ordering
RX Reed-Solomon Interleave Value
RX 8-PSK 2/3 IESS-310 Operation
LNB Power
LNB Voltage
LNB Reference
LNB Current Monitor Low Current Threshold
LNB Current Monitor High Current Threshold
The demodulator configuration status command causes a
block of data to be returned by the addressed modem. The
block of data reflects the current configuration of the demod.
Additional configuration status of new options and features will
always be appended to the end.
Notes:
1) Data is only returned for the TX/RF L-Band modem
