Displays the current receive signal level.
Range: -135 dBm + 10 log (SR) to -85 dBm + 10log (SR)
Press[
←] or [→] to move the flashing cursor, and [↑] or [↓] to increment or decrement the
selected kbps. Press to execute the change.
FUNCTION SELECT: MONITOR: SWEEP FREQUENCY
SWEEP FREQUENCY
+ 0 Hz
Displays the current offset frequency or “No Data” (if carrier is not locked).
Range: -500,000 to +500,000 Hz.
Press[
←] or [→] to move the flashing cursor, and [↑] or [↓] to increment or decrement the
selected kbps. Press to execute the change.
FUNCTION SELECT: MONITOR: BUFFER FILL
BUFFER FILL
50%
Displays the current plesiochronous buffer fill status percent. Range: 1 to 99%.
FUNCTION SELECT: MONITOR: FRAME ERRORS (CONDITIONAL)
FRAME ERRORS
n.n E-e
2047 ERRORS
n.n E-e
