SNM-1001L Satellite Modem Revision 1
Front Panel Operation MN/SNM1001L.IOM
4–44
FUNCTION SELECT: MONITOR: ODU PLL LOCK (CONDITIONAL)
ODU PLL LOCK
OK/UNLOCKED
IMPORTANT
Conditional: This menu is displayed when FSK and ODU POWER
SUPPLY are ON under the Configuration: Modulator menu.
Displays the ODU PLL Lock status of an FSK capable BUC. The ODU PLL requires that the
ODU 10 MHz reference is On under the Configuration: Modulator menu.
FUNCTION SELECT: MONITOR: ODU SOFTWARE (CONDITIONAL)
ODU SOFTWARE
VER: XX
IMPORTANT
Conditional: This menu is displayed when FSK and ODU POWER
SUPPLY are ON under the Configuration: Modulator menu.
Displays the ODU current software version 0 to 15 of an FSK capable BUC.
FUNCTION SELECT: MONITOR: ODU POWER CLASS (CONDITIONAL)
ODU POWER CLASS
XX WATTS
IMPORTANT
Conditional: This menu is displayed when FSK and ODU POWER
SUPPLY are ON under the Configuration: Modulator menu.
Displays the Power Class from 0 to 60 watts of an FSK capable BUC.
