SNM-1001L Satellite Modem Revision 1
Front Panel Operation MN/SNM1001L.IOM
4–45
FUNCTION SELECT: MONITOR: TX L-BAND FREQ (CONDITIONAL)
TX L-Band FREQ
1200.0000 MHz
IMPORTANT
Conditional: This menu is displayed when the TX Terminal LO
(frequency) and Mix are programmed under the Utility: Modulator TX
Terminal LO menu.
Displays the TX L-Band frequency within 950 to 1750 MHz.
FUNCTION SELECT: MONITOR: RX L-BAND FREQ (CONDITIONAL)
RX L-Band FREQ
1200.0000 MHz
IMPORTANT
Conditional: This menu is displayed when the RX Terminal LO
(frequency) and Mix is programmed under the Utility: Demodulator RX
Terminal LO menu.
Displays the TX L-Band frequency with 950 to 1750 MHz.
4.3.3 FUNCTION SELECT: FAULTS/ALARMS
FUNCTION SELECT
FAULTS/ALARMS
Press to review or edit the following sub-menus.
Line 2 of the display shows the current Faults/Alarms status in real time. For each parameter
monitored, fault status is displayed as one of the following:
• “–” indicates that no fault or alarm exists.
• “+” indicates that a fault exists, and will cause switching in a redundant system.
• Reversed contrast “+” indicates an active alarm.
