SNM-1001L Satellite Modem Revision 1
Front Panel Operation MN/SNM1001L.IOM
4–79
FUNCTION SELECT: UTILITY: SYSTEM: REMOTE BAUD RATE
REMOTE BAUD RATE
9600 bps EVEN
The parity and baud rate settings of the modem are displayed.
To change the modem baud rate and/or parity, press . Press [
←] or [→] to position the
cursor over the parameter to be changed. Press [ ↑] or [↓] to change the parameter. Once the
parameters are displayed as desired, press to set the baud rate and parity. The parity can
be set to EVEN, ODD, or NONE. The baud rate can be set from 150 to 19200 bps.
FUNCTION SELECT: UTILITY: SYSTEM: REMOTE ADDRESS
REMOTE ADDRESS
1
The current modem address is displayed (1 to 255).
To change the remote address, press . Press [
↑] or [↓] to make the selection. Press
[ENTER] to execute the change.
Note: Address 0 is reserved has a Global Address.
FUNCTION SELECT: UTILITY: SYSTEM: REMOTE TYPE
REMOTE TYPE
RS485 (2-WIRE)
Select EIA-485(2-Wire), EIA-485(4-Wire), or EIA-232.
