SNM-1001L Satellite Modem

Revision 1

Front Panel Operation

MN/SNM1001L.IOM

4–11

FUNCTION SELECT: CONFIGURATION: MODULATOR:
TX-IF OUTPUT

TX-IF OUTPUT

OFF

Programs the modulator output On or Off. Upon entry, the current status of the output is
displayed. Press [

↑] or [↓] to make the selection. Press to execute the change.

FUNCTION SELECT: CONFIGURATION: MODULATOR:

TX POWER LEVEL

- 10.0 dBm

Programs the modulator output power level from 0 to -40 dBm

Upon entry, the current transmitter power level is displayed with the flashing cursor on the first
character. Press [

↑] or [↓] to increase or decrease the output power level in 0.1 dBm steps. Press

to execute the change.

TX POWER LEVEL

-10.0 dBm (ADJ)

This menu appears when:

1. ODU Power Leveling is On (Utility: Outdoor Unit), or
2. The MOD Power Offset (Utility: Modulator is

≠ 0 dB.).

3. (ADJ) appears after the power level in the TX Power Level screen when this menu is

active.

Notes:
1.

When Power Leveling is Enabled, manual changes to the output level are inhibited, and
the menu indicates the TX Power Level TX by the modulator.

When MOD power offset is active the output power is adjusted [

↑] and [↓] with arrow

keys. However, the value indicated in the display is:

Modulator Power Level + Offset
