SNM-1001L Satellite Modem Revision 1
Remote Control Operation MN/SNM1001L.IOM
B–22
Interface
Read Error
Status Command:
Response:
>add/IRES_tttt_xn.nE-ee'cr''lf']
Where:
tttt = FRM (FRAME) or 2047 (indicates type of error
being read).
x = < or > (data modifier to indicate that the error rate is
less than or greater than the returned value).
m.m = 1.0 to 9.9 (error rate mantissa).
ee = 1 to 99 (error rate exponent).
This command returns frame or 2047 error rate. The 'IRE_'
configuration command is used to select reading of frame or
2047 errors.
Notes:
1. The 'x' (< or >) parameter is only returned if the
error rate has exceeded the computational
resolution of the system.
2. 'No Data' is returned if the error rate cannot be
calculated.
3. 'Sampling' is returned if not enough data is currently
available to calculate the error rate.
Eb/N0 Status Command:
Response:
>add/EBN0_xnn.ndB'cr''lf']
Where:
x = < or > (data modifier to indicate that the Eb/N0 is less
than or greater than the returned value).
nn.n = 1.0 to 99.9 (Eb/N0 value).
Notes:
1. The 'x' (< or >) parameter is only returned if the
Eb/N0 has exceeded the computational resolution
of the system.
2. 'No Data' is returned if the Eb/N0 cannot be
calculated.
3. 'Sampling' is returned if not enough data is currently
available to calculate the Eb/N0.
Modulator
Rate Status Command:
Response:
>add/MR_nnnn_mmmm.mmm'cr''lf'] Where:.
nnnn = 1/2 (QPSK 1/2 Turbo and non-Turbo), [coder
rate], 3/4 (QPSK 3/4Turbo and non-Turbo), 7/8 (QPSK
7/8), BP12 (BPSK 1/2), 8P23 (8PSK 2/3), OQ12
(OQPSK 1/2 Turbo and non-Turbo), OQ34 (OQPSK 3/4
Turbo and non-Turbo), OQ78 (OQPSK 7/8), BPSK
(BPSK1/1 Turbo and non-Turbo), QPSK (QPSK 1/1
Turbo and non-Turbo), OQSK (OQPSK 1/1 Turbo, and
non-Turbo), 2144 (BPSK 21/44 Turbo Only), B516
(BPSK 5/16 Turbo Only), and 8P34 (8PSK 3/4 Turbo
Only).
mmmm.mmm = Data rate in kHz
Burst Mode = nnnn= 1/2
mmmm.nnn = 19.2 or 57.6 kbps
Demodulator
Rate Status Command:
Response:
>add/DR_nnnn_mmmm.mmm'cr''lf']
Where:
nnnn = 1/2 (QPSK 1/2 Turbo and non-Turbo), [coder
rate], 3/4 (QPSK 3/4 Turbo and non-Turbo), 7/8 (QPSK
7/8), BP12 (BPSK 1/2), 8P23 (8PSK 2/3), OQ12
(OQPSK 1/2 Turbo and non-Turbo), OQ34 (OQPSK 3/4
Turbo and non-Turbo), OQ78 (OQPSK 7/8), BPSK
(BPSK1/1 Turbo and non-Turbo), QPSK (QPSK 1/1
Turbo and non-Turbo), OQSK (OQPSK 1/1 Turbo, and
non-Turbo), 2144 (BPSK 21/44 Turbo Only), B516
(BPSK 5/16 Turbo Only), and 8P34 (8PSK 3/4 Turbo
Only).
mmmm.mmm = Data rate in kHz.
Burst Mode = nnnn= 1/2
mmmm.nnn = 19.2 or 57.6 kbps
