Table 3-1. Modem Rear Panel Connectors
Name
Ref.
Desig. Connector Type Function
TX/IF OUTPUT CP1 Type N , Female RF Output
EXT REF CP2 BNC, Female EXT REF IN
RF IF INPUT CP3 Type F, Female RF Input 75 Ω
REMOTE J6 9-pin D, Female Remote Interface
FAULT J7 9-pin D, Female FORM C Fault Relay Contacts
DATA I/O
(Customer-select)
J8
25-pin D, Female
34-pin, Female
37-pin D, Female
50-pin D, Female
Data Input/Output (standard modem)
V.35
EIA-449
Data Input/Output
AUX 1 J9 9-pin D, Female (TTL) Faults
Satellite Clock
Demod I/Q
Automatic Gain Control (AGC) Out
ALARMS J10 9-pin D, Female FORM C Alarm
Relay Contacts
AC INPUT NONE IEC
GROUND NONE 10-32 Stud
Note: The European EMC Directive (EN55022, EN50082-1) requires using properly shielded
cables for DATA I/O. These cables must be double-shielded from end-to-end, ensuring a
continuous ground shield.
