SNM-1001L Satellite Modem
Revision 1
Remote Control Operation MN/SNM1001L.IOM
B–26
Bulk Consol.
Analog
Status
Command:
Response:
This command is similar to the 'BCS_' command, but
returns modem analog parameters. Additional status
of new options and features will always be appended
to the end.
Where 'pn' is the last parameter returned.
Parameter
Number
Parameter Name
(Command Reference)
Description
1
2
3
4
5
6
7
8
Receive Signal Level
(ref. 'RSL_' command).
Raw BER
(ref. 'RBER_' command).
Corrected BER
(ref. 'CBER_' command).
Interface Read Error Status
(ref. 'IRES_' command).
EB/N0
(ref. 'EBN0_' command).
Buffer Fill Status
(ref. 'IBFS_' command).
LNB Current
(ref. LNBC_’ command).
ODU Current
(ref. ODUC_’ command).
p1 = xsnn.n, receive signal level in dBm.
p2 = xm.mE-ee.
p3 = xm.mE-ee.
p4 = tttt_xm.mE-ee.
p5 = xnn.n, EB/N0 in dB.
p6 = nn%, buffer fill status.
P7 = nnn, LNB Current
P8 = nnnn, ODU Current
Note: Parameters 2 through 6 are dependent on carrier acquisition, if the decoder is not locked empty data blocks are returned
(,,,,,).
