SNM-1001L Satellite Modem Revision 1
Front Panel Operation MN/SNM1001L.IOM
4–73
FUNCTION SELECT: UTILITY: DEMODULATOR:
RX IESS-310 MODE (CONDITIONAL)
RX IESS-310 MODE
OFF
IMPORTANT
Conditional: Note: Only available when the 8-PSK option is selected and
Reed-Solomon option is installed and selected.
Selection of On or Off used for 8-PSK 2/3 with Reed-Solomon.
FUNCTION SELECT: UTILITY: DEMODULATOR: LNB ALARM - LOW
LNB ALARM - LOW
0 mA
Status Only. Programmable within 0 to 500 mA, in 1 mA steps.
An alarm is generated whenever the LNB current falls below the programmed limit.
FUNCTION SELECT: UTILITY: DEMODULATOR: LNB ALARM - HIGH
LNB ALARM - HIGH
500 mA
Status Only. Programmable within 0 to 500 mA, in 1 mA steps. An alarm is generated whenever
the LNB current exceeds the programmed limit.
Note: The low limit must be less than the high limit.
