SNM-1001L Satellite Modem Revision 1
Front Panel Operation MN/SNM1001L.IOM
4–37
FUNCTION SELECT:CONFIGURATION:LOCAL AUPC:
REMOTE CL ACTION (CONDITIONAL)
REMOTE CL ACTION
HOLD
IMPORTANT
Conditional: This menu is displayed when Local Modem AUPC = ON
located under the Utility: Modem Type menu.
Programs the Remote Carrier Loss action (CL) for HOLD, NOMINAL, or MAXIMUM. The
modulator carrier at the local end moves to this value upon carrier loss at the remote end. This
only applies to remote AUPC between two carriers.
HOLD Upon Carrier Loss (CL) the carrier level remains at the level just before carrier loss.
NOMINAL Upon CL the TX Carrier Level reverts to the Nominal Power Level programmed
under Configuration: Local AUPC: Nominal Power
MAXIMUM Upon CL the TX Carrier Level is programmed to the level programmed under
Configuration: Local AUPC: Maximum Power.
4.3.1.5 FUNCTION SELECT: CONFIGURATION: SAVE
CONFIGURATION
SAVE
CONFIGURATION SAVE: 1, 2, 3, 4 or 5
The Configuration Save menu allows programming of configuration parameters into non-volatile
memory on the M&C. There are five memory locations that may be used to store specific
configuration setups that are used frequently.
After changing the configuration parameters to the desired settings, enter the Configuration Save
menu and select memory location 1 through 5. Press to execute the save.
