SNM-1001L Satellite Modem Revision 1
Remote Control Operation MN/SNM1001L.IOM
B–24
B.5 Stored Faults
Information on stored faults is returned when requested. If no stored fault exists for a given fault
number, the words “NO Fault” will be returned instead of the normal time/date status
information.
The following symbols are commonly used to define the stored faults status commands:
# = Fault number (0 to 9). “0” is the first fault stored.
hh = Hours in 24-hr. format.
mm = Minutes.
ss = Seconds.
MM = Month.
DD = Day
YYYY = Year.
Modulator
Stored Faults Command:
Response: >add/MSF_# hh:mm:ss MM/DD/YYYYY'cr'
MOD_xxx'cr'
SYN_xxx'cr'
DCS_xxx'cr'
ICH_xxx'cr'
QCH_xxx'cr'
AGC_xxx'cr'
SCT_xxx'cr'
EXT_xxx'cr'
CONF_xxx'cr''lf']
Module (OK/FLT)
IF Synthesizer (OK/FLT)
Data Clock Synthesizer (OK/FLT)
I Channel (OK/FLT)
Q Channel (OK/FLT)
AGC Level (OK/FLT)
Modem Reference PLL Lock (OK/FLT)
Modem Reference Activity (OK/FLT)
Configuration (OK/FLT)
Demodulator
Stored Faults Command:
Response:
>add/DSF_# hh:mm:ss MM/DD/YYYY'cr'
MOD_xxx'cr'
CD_xxx'cr'
SYN_xxx'cr'
ICH_xxx'cr'
QCH_xxx'cr'
BERT_xxx'cr'
CONF_xxx'cr''
LNB_xxx’cr’’lf’]
Demod Module (OK/FLT)
Carrier Detect (OK/FLT)
IF Synthesizer Lock (OK/FLT)
I Channel (OK/FLT)
Q Channel (OK/FLT)
BER Threshold (OK/FLT)
Configuration (OK/FLT)
LNB (OK/FLT)
Interface
Transmit
Side Stored
Faults Command:
Response:
>add/ITSF_# hh:mm:ss MM/DD/YYYY'cr'
DRP_xxx'cr'
TXD_xxx'cr'
PLL_xxx'cr'
CLK_xxx'cr'
TAC1_xxx'cr'
TAC2_xxx'cr'
CONF_xxx'cr''lf']
D&I Drop (OK/FLT)
Transmit Data/AIS (OK/FLT)
Transmit Synthesizer PLL Lock (OK/FLT)
Selected Transmit Clock Activity (OK/FLT)
Transmit Audio Clip Channel #1 (OK/FLT)
Transmit Audio Clip Channel #2 (OK/FLT)
Configuration (OK/FLT)
Interface
Receive Side
Stored Faults Command:
Response:
>add/IRSF_# hh:mm:ss MM/DD/YYYY'cr'
UNFL_xxx'cr'
OVFL_xxx'cr'
RXD_xxx'cr'
FBER_xxx'cr'
BWA_xxx'cr'
CLK_xxx'cr'
PLL_xxx'cr'
DMUX_xxx'cr'
2047_xxx'cr'
BUFF_xxx'cr'
INS_xxx'cr'
RAC1_xxx'cr'
RAC2_xxx'cr'
CONF_xxx'cr''lf']
Buffer Underflow (OK/FLT)
Buffer Overflow (OK/FLT)
Receive Data Loss/AIS (OK/FLT)
Frame BER (OK/FLT)
Receive Backward Alarm (OK/FLT)
Selected Buffer Clock Activity (OK/FLT)
Buffer Clock PLL Lock (OK/FLT)
Demux Lock (OK/FLT)
2047 Pattern Lock Detect (OK/FLT)
Buffer Full (OK/FLT)
D&I Insert (OK/FLT)
Receive Audio Clip Channel #1 (OK/FLT)
Receive Audio Clip Channel #2 (OK/FLT)
Configuration (OK/FLT)
