Single Thread System Installation
High-Power C-Band Satellite Terminal
3–4
Rev. 0
3.2
Inspecting the Equipment
1. Carefully check the equipment for possible damage incurred during shipment.
2. Carefully check the equipment against the packing list shipped with the
equipment to ensure that the shipment is complete.
3.2.1 Included
Parts
A typical HPCST-5000 single thread configuration contains the following components.
Notes:
1. Hardware required for this configuration is located in Chapter 8, Equipment List.
2. Because each system can be custom ordered, it is beyond the scope of this
manual to provide the unlimited configuration possibilities.
3. This chapter does not describe the installation procedures for amplifiers, or high
performance LNAs.
Qty.
Description
Qty.
Description
1
RFT outdoor unit
1
Low noise amplifier (LNA)
R
F
IN
R
F
O
U
T
M
O
D
E
L
N
O
.
S
E
R
IA
L
N
O
.
F
R
E
Q
U
E
N
C
Y
N
O
IS
E
T
E
M
P
G
A
IN
.
1
C-Band SSPA
1
Installation and operation manuals for the
following:
! HPCST-5000
!
Monitor and Control Software
1
Envelope containing the test data sheet
