Configurations High-Power C-Band Satellite Terminal
A–6 Rev. 0
3620 TO 4200 MHz
-40 dBm (TYP)
SMA FEM ALE
RF INPUT
DOWN CONVERTER
FROM
SYNTHESIZER
FROM IFLO
PHASE
EQUALIZER
ATTENUATOR
SMA FEMALE
140.0 MHz (+/-36 MHz)
2nd IF OUTPUT
4592.5 TO
5172.5 MHz
+8 dBm
SMA FEMALE
1112.5 MHz
+8 dBm
SMA FEMALE
LO INPUT
LO INPUT
Figure A-4. Down Converter Block Diagram
