Theory of Operation High-Power C-Band Satellite Terminal
6–8 Rev. 0
6.1.5.4 Synthesizers (DC/UC/LO), J4 DB37-Female
Refer to Table 6-4 for pin assignments.
Table 6-4. Synthesizers (DC/UC/LO), J4 DB37-Female
Pin # Name Description
1 UC LO A0 Output CMOS level, LSB (selects the 2nd
20 UC LO A1 Output CMOS level, 2LSB divide-by number)
2 UC LO A2 Output CMOS level, 2MSB
21 UC LO A3 Output CMOS level, MSB
3 UC LO G0 Output CMOS level, LSB (selects gain over
22 UC LO G1 Output CMOS level, 2LSB frequency)
4 UC LO G2 Output CMOS level, 2MSB
23 UC LO G3 Output CMOS level, MSB
5 UC LO N0 Output CMOS level, LSB (selects the first
24 UC LO N1 Output CMOS level, 2LSB divide-by number
6 UC LO N2 Output CMOS level, 3LSB in the synthesizer)
25 UC LO N3 Output CMOS level, 3MSB
7 UC LO N4 Output CMOS level, 2MSB
26 UC LO N5 Output CMOS level, MSB
8 DC LO LCK DET Input, 0V = locked, 5V = unlocked
27 DC LO T_MON Input, 0 to 11V, nominal reading = 6V
9 SPARE
28 SPARE
10 IF LCK DET Input, 0V = locked, 5V = unlocked
29 IF T_MON Input, 0 to 11V, nominal reading = 6V
11 SPARE
30 DC LO A0 Output CMOS level, LSB (selects the 2nd
12 DC LO A1 Output CMOS level, 2LSB divide-by number)
31 DC LO A2 Output CMOS level, 2MSB
13 DC LO A3 Output CMOS level, MSB
32 DC LO G0 Output CMOS level, LSB (selects gain
14 DC LO G1 Output CMOS level, 2LSB over frequency)
33 DC LO G2 Output CMOS level, 2MSB
15 DC LO G3 Output CMOS level, MSB
34 DC LO N0 Output CMOS level, LSB (selects the first
16 DC LO N1 Output CMOS level, 2LSB divide by number
35 DC LO N2 Output CMOS level, 3LSB in the synthesizer)
17 DC LO N3 Output CMOS level, 3MSB
36 DC LO N4 Output CMOS level, 2MSB
18 DC LO N5 Output CMOS level, MSB
37 UC LO LCK DET Input, 0V = locked, 5V = unlocked
19 UC LO T_MON Input, 0 to 11V, nominal reading = 6V
