Comtech EF Data HPCST-5000 User Manual
Page 56
Single Thread System Installation
High-Power C-Band Satellite Terminal
3–2
Rev. 0
RX/RF IN
(J4)
RFT-500
TX/RF
OUT (J2)
PRIME
POWER
(J5)
TX/IF
INPUT (J1)
RX IF
OUT
DISCRETE/IF (J3)
RF INPUT
(J1)
METAL PLATE
(J6)
TX/RX
OUT (J7)
(TO ANTENNA)
AC LINE
(J5)
METAL
PLATE
(J2)
Figure 3-1. HPCST-5000 Single Thread Configuration Schematic
