High-Power C-Band Satellite Terminal Theory of Operation
Rev. 0 6–21
6.6.1 Specifications
Refer to Table 6-10 for up converter specifications.
Table 6-10. Up Converter Specifications
Up Converter
Input Frequency 70 MHz # 18 MHz
Input Connector SMA Female
Input Impedance 50
$
Input VSWR 1.3:1
Output Frequency 5845 to 6425 MHz
Output Connector SMA Female
Output VSWR 1.5:1
1 dB Compression +10 dBm
1st RF Local Oscillator Input
Frequency 1060 MHz
Level +8 dBm
Connector SMA Female
Return Loss 14 dB
Impedance 50
$
2nd RF Synthesizer Input
Frequency 4715 to 5295 MHz
Level +8 dBm
Connector SMA Female
Return Loss 14 dB
Impedance 50
$
