1.8 RFT Specification
Refer to Table 1-12 for RFT-500 specifications.
Table 1-12. RFT-500 Specifications
Transmit Characteristics
Output Frequency (No Inversion) 5.845 to 6.425 GHz
Input Frequency 70 # 18 MHz
140
# 36 MHz (optional)
Output Power at 1 dB compression +8 dBm
Third Order Intercept +18 dBm (for +8 dBm)
Nominal Small Signal Gain 26 dB (for +8 dBm)
Gain Adjust Range 0 to 25 dB, in 0.5 dB steps
Gain Variation:
Over 36 MHz
Over 36 MHz, Temperature and Aging # 1 dB maximum
# 2 dB maximum
Noise Figure:
Maximum Attenuation
Minimum Attenuation 23 dB maximum
15 dB maximum
Group Delay (any 36 MHz):
Linear
Parabolic
Ripple
% 30 ns
0.28 ns/MHz
0.15 ns/MHz
2
% 1 ns P-P
Synthesizer Step Size 2.5 MHz (optional 125 kHz)
Phase Noise (SSB) at:
10 Hz
100 Hz
1 kHz
10 kHz
100 kHz
-30 dBc/Hz
-60 dBc/Hz
-70 dBc/Hz
-75 dBc/Hz
-80 dBc/Hz
Or
% 2.8! rms (DSB)
integrated 10 Hz to
1 MHz
Frequency Stability:
Annual at 23 ! C
Over Temperature
After 30 Minutes Warm-up
Electrical Adjustment
# 1 x 10 -7
# 1 x 10 -8 (-40 ! to +55 ! C) (-40 ! to +131 ! F)
# 1 x 10 -8
0.5 x 10 -7
Isolation on Fault Shutdown -60 dBc minimum
Spurious:
< 250 kHz Carrier Offset
> 250 kHz Carrier Offset -35 dBc maximum
-50 dBc maximum
RF Output VSWR 1.5:1 at 50
$
RF Output Connector N-Type female
IF Input VSWR 1.5:1 at 50
$
IF Input Connector TNC female
