High Power C-Band Satellite Terminal Introduction
Rev. 0 1–17
1.7.4 HPCST-5000 Monitor and Control
The HPCST-5000 terminal system has a single interface connector (J16) located on the
RSU-503L for redundant configurations. For single thread configuration, the M&C is
connected to connector (P1) on the RFT-500. The interface provides the customer with
control of the terminal system redundant configuration including the C-Band SSPA
through the integrated system cable harness. The options for customer control of the
terminal system are provided in Table 1-8.
Table 1-8. System Monitor and Control
System Type Interface M&C Options
HPCST-5000 Terminal
System EIA-232/EIA-485 Serial Bus On-board Keypad, KP-10 Handheld
Keypad, or ASCII terminal through J16
of the RSU-503L.
