Remote Control Operation High Power C-Band Satellite Terminal
B–4 Rev. 0
B.3 Configuration Commands/Responses
Up
Converter
Frequency
Select Command:
Response:
Status:
Response:
>add/UCF_nnnn.nnn'cr'
RF_OFF'cr''lf']
>add/UCF_nnnn.nnn'cr''lf']
Where: nnnn.n = 5845.000 to 6425.000 MHz, in 125 kHz
steps.
Down
Converter
Frequency
Select Command:
Response:
Status:
Response:
>add/DCF_nnnn.nnn'cr''lf']
>add/DCF_nnnn.nnn'cr''lf']
Where: nnnn.n = 3620.000 to 4200.000 MHz, in 125 kHz
steps.
RF Output Command:
Response:
Status:
Response:
>add/RF_xxx'cr''lf']
>add/RF_xxx'cr''lf']
Where: xxx = ON, WRM, or OFF.
The OFF command will keep the RF output turned off under all
conditions, the WRM command is a conditional ON command
telling the RF output to come on after the unit is warmed up
and meets the stability requirements, while the ON command
is an override instructing the output to be on and ignores the
warm start.
UP
Converter
Attenuator Command:
Response:
Status:
Response:
>add/UCA_nn.n'cr''lf']
>add/UCA_nn.n'cr''lf']
Where: nn.n = 0.0 to 25.0 dB, in 1/2 dB steps.
Down
Converter
Attenuator Command:
Response:
Status:
Response:
>add/DCA_nn.n'cr''lf']
>add/DCA_nn.n'cr''lf']
Where: nn.n = 0.0 to 21.0 dB, in 1/2 dB steps.
