High Power C-Band Satellite Terminal Remote Control Operation
Rev. 0 B–5
Select
Preset
Config. Command:
Response:
Status:
Response:
>add/SEL_n'cr''lf']
>add/SEL_'cr'
1
UCF_nnnn.nnn'cr'
DCF_nnnn.nnn'cr'
UCA_nn.n'cr'
DCA_nn.n'cr'
2
UCF_nnnn.nnn'cr'
DCF_nnnn.nnn'cr'
UCA_nn.n'cr'
DCA_nn.n'cr'
3
UCF_nnnn.nnn'cr'
DCF_nnnn.nnn'cr'
UCA_nn.n'cr'
DCA_nn.n'cr''lf']
Where: n = 1, 2, or 3.
1
nnnn.nnn = 5845.000 to 6425.000 MHz.
nnnn.nnn = 3620.000 to 4200.000 MHz.
nn.n = 0.0 to 25.0 dB (UC Fine Adj).
nn.n = 0.0 to 21.0 dB (DC Fine Adj).
2
nnnn.nnn = 5845.000 to 6425.000 MHz.
nnnn.nnn = 3620.000 to 4200.000 MHz.
nn.n = 0.0 to 25.0 dB (UC Fine Adj).
nn.n = 0.0 to 21.0 dB (DC Fine Adj).
3
nnnn.nnn = 5845.000 to 6425.000 MHz.
nnnn.nnn = 3620.000 to 4200.000 MHz.
nn.n = 0.0 to 25.0 dB (UC Fine Adj).
nn.n = 0.0 to 21.0 dB (DC Fine Adj).
Allows the user to select any one of three 'PreSet'
configurations. The users must first program (store) a
configuration using the PGM_n command defined below. This
command used without the 'PreSet' number (n) will provide the
current programming of each of the three 'PreSets'.
Program
Preset
Config. Command:
Response:
Status:
Response:
>add/PGM_n'cr''lf']
>add/PGM_'cr'
1 xxxxxxxxxx'cr'
2 xxxxxxxxxx'cr'
3 xxxxxxxxxx'cr''lf']
Where:
n = 1, 2, or 3.
xxxxxxxxxx = 'Programmed' or 'None'.
Allows the user to store (program) the current frequency and
attentuator setting as one of three 'PreSet' selections.
Clear
Program
Preset
Config. Command:
Response:
Status:
Response:
>add/CPGM_n'cr''lf']
>add/CPGM_'cr''lf']
1 xxxxxxxxxx'cr'
2 xxxxxxxxxx'cr'
3 xxxxxxxxxx'cr''lf']
Where:
n = 1, 2, or 3.
xxxxxxxxxx = 'Programmed' or 'None'.
Allows the user to clear (unprogram) the frequency and
attentuator setting for one of three 'PreSet' selections.
