Comtech EF Data HPCST-5000 - Manual (Page 119)

High-Power C-Band Satellite Terminal Operation
Rev. 0 5–7
Function Description
SELECT Selects any one of the “preset” configurations. The user must first program (store)
configuration parameters in the PROGRAM menu.
On entry, the current Select parameter will appear in the menu. Press [ $ ] or [ % ] to
select 1, 2, 3, or None. Press [ENTER] to execute the change. If no parameters have
been selected in the PROGRAM menu, default configurations will be loaded.
RF OUTPUT Programs the RF output to ON, WRM, or OFF.
On entry, the current status of the output is displayed. Press an Arrow key to select
ON, WRM, or OFF. Press [ENTER] to execute the change.
U/C FREQ Programs the up converter frequency between 5845 and 6425 MHz, in:
VER: 7.00: 2.5 MHz steps.
VER: 8.00: 125 kHz steps
On entry, the current up converter frequency is displayed with the flashing cursor on
the first character. Press [
" ] or [ # ] to move the flashing cursor. Press [ $ ] or [ % ] to
increment or decrement the digit at the flashing cursor. Press [ENTER] to execute the
change.
Note: The frequency is programmable within the specified range. When the
transmitter frequency is changed, the transmitter is automatically turned OFF to
prevent the possible swamping of other channels. To turn the transmitter ON, use the
RF OUTPUT menu.
D/C FREQ Programs the down converter frequency between 3620 and 4200 MHz, in:
VER: 7.00: 2.5 MHz steps.
VER: 8.00: 125 kHz steps
On entry, the current down converter frequency is displayed with the flashing cursor
on the first character. Press [
" ] or [ # ] to move the flashing cursor. Press [ $ ] or [ % ]
to increment or decrement the digit at the flashing cursor. Press [ENTER] to execute
the change.
U/C ATTN Programs the up converter output power attenuation from 0 to 25 dB, in 0.5 dB steps.
On entry, the current up converter attenuation is displayed with the flashing cursor on
the first character. Press [
$ ] or [ % ] to increase or decrease the output power
attenuation in 0.5 dB steps. Press [ENTER] to execute the change.
D/C ATTN Programs the down converter input power attenuation from 0 to 21 dB, in 0.5 dB
steps.
On entry, the current down converter attenuation is displayed with the flashing cursor
on the first character. Press [
$ ] or [ % ] to increase or decrease the output power
attenuation in 0.5 dB steps. Press [ENTER] to execute the change.
PROGRAM Programs or clears the current frequency and attenuator settings as one of the three
“preset” selections.
On entry, 1*, 2*, or 3* will appear in the window. Press [ " ] or [ # ] to move the
cursor from left to right. When the flashing cursor is on any of the “*”s, press [ $ ] or
[ % ] to turn the “*” ON or OFF. When the “*” is ON, press [ENTER] to clear stored
parameters in the preset location to the left of the “*”. When the “*” is OFF, press
[ENTER] to store the current frequency and attenuation parameters in the preset
location at the cursor. To recall any of the present selections, use the SELECT menu,
and select 1, 2, or 3. Press [ENTER].
