External Connections High-Power C-Band Satellite Terminal
2–4 Rev. 0
2.1.1.5 Prime Power (J5)
The AC power is supplied to the RFT by a 3-pin circular connector.
Normal input voltage is 90 to 265 VAC, 47 to 63 Hz, and 90W.
The AC pinout is as follows:
Pin # Name Function Wire Color
A HI Line Brown
B LO Neutral/Line Blue
C GND Ground Green/Yellow
2.1.1.6 Serial Remote Control (J6)
The remote connector on the RFT is used to interface the M&C functions to a remote
location. This interface can be either EIA-232 or EIA-485 (Figure 2-2).
When using an EIA-485 interface, the TX and RX signals are able to accommodate
either type of remote equipment pinouts. As long as the polarities of the remote
equipment TX and RX signals are correct, this remote interface will be completely
compatible.
Refer to Table 2-2 for a list of pinouts for the J6 connector.
For standard EIA-232 or EIA-485 applications, an adapter cable must be used to connect
the 26-pin connector (J6) to a standard 9-pin D.
