Introduction High-Power C-Band Satellite Terminal
1–26 Rev. 0
Refer to Figure 1-8 for C-Band SSPA dimensional requirements.
Note: All dimensions are in inches, centimeters are in parenthesis.
9.80
(24.89)
0.40
(6 PLACES)
0
9.07
(23.03)
1.47
(3.73)
2.54
(6.45)
9.09
(23.08)
A
DIMENSION A
75W 100W 125W 150W
16.15
(40.89)
18.27
(46.41)
18.27
(46.41)
18.27
(46.41)
Figure 1-8. C-Band SSPA Dimensional Requirements
