High Power C-Band Satellite Terminal Equipment List
Rev. 0 8–11
8.2.4 Universal Mounting Kit
Fig. &
Item No.
Part No. 1234567 Nomenclature Qty
8-4 -1 KT/3576 Kit, Universal Mounting Ref
-1A KT/6698 Kit, Universal Mounting Ref
-2 FP/3175 . Bracket, Spar Mounting (See Figure 8-3) 4
-3 HW/5/16-18 x 1BLT . Bolt, 5/16-18 x 1” (AP) 8
-4 HW/5/16-SPLIT . Washer, Split Lock (AP) 8
-5 HW/5/16-FLT . Washer, Flat (AP) 8
-6 HW/5/16-18SPNUT . Nut, Spring (AP) 8
7 FP/3481 . Unistrut, 8”-Long 4
8 HW/1/4-20 x 5/8BT . Bolt, 1/4-20 x 5/8” (AP) 8
9 HW/1/4-SPLIT . Washer, Split Lock (AP) 8
10 HW/1/4-FLT . Washer, Flat (AP) 8
11 HW/FIT-PLT-5/16 . Plate, Flat Fitting 16
12 HW/5/16-18SPNUT . Nut, Spring Nut 32
13 FP3595 . Unistrut, 14”-Long 8
14 HW/5/16-18 x 1BLT . Bolt, 5/16-18-1” (AP) 24
15 HW/5/16-SPLIT . Washer, Split Lock (AP) 36
16 HW/5/16-FLT . Washer, Flat (AP) 36
17 HW/5/16-18SPNUT . Nut, Spring (AP) 8
18 HW/BLK-PIPE2-8 . Block, Pipe, 2-8 inch, 1 5/8 UNI Channel 16
19 HW/RD5/16-18 x 14 . Rod, Threaded, 5/16-18 x 14” 8
20 HW/5/16-18HEXNT . Nut, Hex, 5/16-18 24
21 HW/5/16-SPLIT . Washer, Split Lock 12
22 HW/5/16-FLT . Washer, Flat 12
23 HW/3/8-16 x 1 BLT . Bolt, 3/8 x 1” 4
24 FP/6487-1 . Bracket, Mounting, Single Thread 1
25 HW/3/8-16 x 1.25B . Bolt, 3/8 x 1 1/4” (AP) 4
26 HW/3/8-SPLIT . Washer, Split Lock (AP) 8
27 HW/3/8-FLT . Washer, Flat (AP) 8
28 HW/3/8-16HEXNUT . Nut, Hex, 3/8-16 (AP) 4
-Item Not Illustrated
AP = Attaching Parts
