High Power C-Band Satellite Terminal Introduction
Rev. 0 1–27
Refer to Figure 1-9 and Figure 1-10 for standard LNA dimensional requirements.
Note: All dimensions are in inches, centimeters are in parenthesis.
14.50
(36.8) 6.35
(16.12)
1.50
(3.81)
2.85
(7.23)
2.85
(7.23)
8.99
(22.83)
.75
(1.90)
7.50
(19.05)
RF OUTPUT, VCC INPUT
N CONNECTOR, FEMALE
1.69
(4.29) .84
(2.13)
3.00
(8.00)
.69
(1.75)
RF IPUT
CPR 229 WAVEGUIDE
Figure 1-9. Single Thread Configuration Dimensional Requirements
