Introduction High-Power C-Band Satellite Terminal
1–16 Rev. 0
Table 1-6. System Interfaces on Units (Continued)
Description Type
RS-503L:
M&C for RFT #A (J4)
IF RX Input (J2)
IF TX Output (J1)
M&C for RFT #B (J8)
IF RX Input (J6)
IF TX Output (J5)
Remote M&C (J16)
IF RX Output (J15)
IF TX Input (J14)
Waveguide Switch (J10) Circular, PT06E-16-26S
TNC, female
TNC, female
Circular, PT06E-16-26S
TNC, female
TNC, female
Circular, PT06E-16-26S
TNC, female
TNC, female
Circular, PT06E-14-19S
M&C Single Thread System with SSPA Circular, KPT06E-16-26P on RFT-500
M&C 1:1 System with SSPA Use J16 on RSU-503L
Waveguide TX Switch with SSPA Circular, MS3112E-14-6S
1.7.3 System Environment Specification
Refer to Table 1-7 for environmental conditions.
Table 1-7. Environmental Specifications
Environment Conditions
Temperature:
Operating
Survival -40
! to +50!C (-40! to 122!F)
-50
! to +70!C (-58! to 158!F) , non-operating
Vibration 1.5g, 5 to 200 Hz and normal transportation levels
Shock 6g maximum
Humidity 0% to 100% relative at -40
! to +50!C (-40! to 122!F)
95% at 55
!C (131!F ) for 72 hours
Precipitation MIL-STD-810/Method 506.2
Salt Fog MIL-STD-810/Method 509.2
Sand and Dust MIL-STD-810/Method 510.1
Altitude:
Operation
Survival 0 to 10,000 ft, derate 2
!C/1000 ft ASL
0 to 40,000 ft
Solar Radiation
360 BTU/hr/ft2 at 50
!C (122!F)
Safety EN60950 (IEC-950, UL 1950)
Emissions EN55022, Class A (FCC Part 15J, Class A)
Immunity EN50082-1
