High Power C-Band Satellite Terminal Equipment List
Rev. 0 8–9
8.2.3 Spar Mounting Kit
Fig. &
Item No.
Part No. 1234567 Nomenclature Qty
8-3 -1 KT/4061 Kit, Spar Mounting, Single Thread Configuration Ref
-1A KT/6699 Kit, Spar Mounting, Single Thread Configuration Ref
2 FP/3175 . Bracket, Spar 4
3 HW/5/16-18 x 1BLT . Bolt, 5/16-18 x 1 Hex Head (AP) 8
4 HW/5/16-SPLIT . Washer, Split (AP) 8
5 HW/5/16-FLT . Washer, Flat (AP) 8
6 HW/5/16-18SPNUT . Nut, Spring (AP) 8
7 FP/3481 . Unistrut, 8”-Long 2
8 HW/1/4-20 x 5/8 BLT . Bolt, 1/4-20 x 5/8 (AP) 8
9 HW/1/4-SPLIT . Washer, Split Lock (AP) 8
10 HW1/4-FLT . Washer, Flat (AP) 8
11 FP/6487-1 . Bracket, Mounting 2
12 HW/3/8-16 x 1.25B . Bolt, 3/8 x 1 1/4 (AP) 4
13 HW/3/8-SPLIT . Washer, Split (AP) 8
14 HW/3/8-FLT . Washer, Flat (AP) 8
15 HW/3/8-16-HEXNUT . Nut, Hex 8
16 FP/3595 . Unistrut, 14”-Long 2
17 HW/3/8-16-1 BLT . Bolt, 3/8 x 1 (AP) 4
18 HW/3/8-SPLIT . Washer, Split Lock (AP) 4
19 HW/3/8-FLT . Washer, Flat (AP) 4
- Item Not Illustrated
AP = Attaching Parts
