High Power C-Band Satellite Terminal Equipment List
Rev. 0 8–15
Fig. &
Item No.
Part No. 1234567 Nomenclature Qty
8-6 -1 KT-6700 Kit, Redundant, Universal Mounting, SSPA REF
2 FP/3175 . Bracket, Support, 1 x 2 Spar 2
3 FP/3482 . Unistrut, 20-inch long 2
4 FP/6488-1 . Bracket, Mounting, Redundant 1
5 FP/6488-2 . Bracket, Mounting, Redundant 1
6 HW/1/2-13HEXNUT . Nut, Hex, 6
7 HW/1/2-FLT . Washer, Flat. 6
8 HW/1/2-SPLIT . Washer, Split Lock, 6
9 HW/3/8-16x3/4B . Bolt, Hex Head, 12
10 HW/3/8-FLT . Washer, Flat, 12
11 HW/3/8-SPLIT . Washer, Split Lock 12
12 HW/5/16-18HEXNT . Nut, Hex, 5/16-18 12
13 HW/5/16-18SPNUT . Nut, Spring 8
14 HW/5/16-18X1BLT . Bolt, , Hex Head 8
15 HW/5/16-FLT . Washer, Flat 20
16 HW/5/16-SPLIT . Washer, Split Lock 20
17 HW/BLK-PIPE2-8 . Pipe, Blocks 8
18 HW/FIT-PLT-5/16 . Plate, Fitting Plate 8
19 HW/RDS/16-18X14 . Rod, Threaded 4
20 FP/3595 . Unistrut, 14-inch long 2
- Item Not Illustrated
