VHDL Monitor BFM
set_transaction_done()
April 2014
set_transaction_done()
This nonblocking procedure sets the transaction_done field for a transaction that is uniquely
identified by the transaction_id field previously created by the
create_monitor_transaction()
procedures.
Note
You do not normally use this procedure in a monitor test program.
Prototype set_transaction_done
(
transaction_done : in integer;
transaction_id : in integer;
bfm_id : in integer;
path_id : in axi4_path_t; --optional
signal tr_if : inout axi4_vhd_if_struct_t
);
Arguments transaction_done Transaction done flag for this transaction
transaction_id Transaction identifier. Refer to “ Overloaded Procedure
Common Arguments ” on page 151 for more details.
bfm_id BFM identifier. Refer to “ Overloaded Procedure Common
Arguments ” on page 151 for more details.
path_id (Optional) Parallel process path identifier:
AXI4_PATH_0
AXI4_PATH_1
AXI4_PATH_2
AXI4_PATH_3
AXI4_PATH_4
Refer to “ Overloaded Procedure Common Arguments ” on
page 151 for more details.
tr_if Transaction signal interface. Refer to “ Overloaded Procedure
Common Arguments ” on page 151 for more details.
Returns None
