13. Enter the remote Location ID (up to 12 alpha/numeric
characters) one character at a time. Use the arrow keys to
move the cursor under the desired character in the character
table or use the numeric keypad to enter numbers. If a
character is being selected from the table, press [Enter] for
each character desired. Enter is not required when entering
numbers from the keypad.
DIALLING
Space
I
Character table
Space
I
A
B
C
D
E
F
G
H
1
J
K
L
M
N
O
P
Q
R
S
T
U
V
w
X
Y
Z
+
-
/
a
b
c
d
e
f
g
h
i
j
k
1
m
n
0
P
q
r
s
t
u
V
w
X
y
Z
+
-
/
0
1
2
3
4
5
6
7
8
9
“
<
=
>
7
@
(
1
{
}
!
#
$
%
&
(
)
*
Display always starts
with first row.
Use UP/DOWN arrow
keys to change rows.
Use LEFT/RIGHT
arrow keys to change
columns.
14. When all the characters have been selected for the remote
location ID, press [Menu].
[P1]=GR0UP NUMBER
SELECT/ENTER
15. If desired number is displayed, press [Select] and [Stop] to
return to the idle mode.
If GROUP NUMBER is displayed, press [Enter] and go to
step 16.
If an undesired number is displayed, press [Clear] and go to
step 16.
[P1]=GR0UP NUMBER
16. Use the terminal keypad to enter the group numbers for the
one touch key. The terminal offers up to five group
numbers, numbered 1 to 5.
If entering more than one group number, press [Menu] to
separate the numbers with a comma.
[P13=GR0UP NUMBER
1, 3, 4
17. When you have selected all the group numbers, press [Enter].
PROGRAM KEY PI TO P6
SELECT AND PRESS
18. Select the next one-touch key, or press [Stop] to return to the
idle mode.
