INSTALUnON
Note: The f^per stop should be set for 11 inch paper when it is
received. If necessary, adjust the paper stop to fit 14 inch paper
by squeezing the sides of the paper stop and sliding it to the 14
inch position.
Advancing the imaging film
1. Press down on the printer cover release button and open the
printer cover.
Locate the imaging cartridge. Note: The red spindle is on
the right rear side. Grasp the cartridge by its handles and lift
it up and out of the terminal.
xvi
TELECOPIER 7024 USER HANDBOOK
