CUSTOM FEATURES AND SETTINGS
To set stop bit (Menu 11, Features 2,3)
1. Press [Menu] to select the menu table.
l.SENO OPTIONSl
01-11
SELECT/ENTER
2. Press [1], [1] to select menu n.
ll.RS-232
01-11
SELECT/ENTER
3. Press [Enter] to select the first feature within the menu.
1.RS-232
1-2
SELECT/START
4. Press [2] to select RS-232 SETTINGS.
2.RS-232 SETTINGS
1-2
SELECT/ENTER
5. Press [Enter] to select the first feature within the menu.
l.SET BAUD RATE
1-4
SELECT/ENTER
6. Press [3] to select SET STOP BIT.
3.SET STOP BIT
1-4
SELECT/ENTER
7. Press [Enter].
STOP BIT:
1
SELECT/ENTER
8. Press [Select] to select 1 or 2.
STOP BIT:
1
SELECT/ENTER
9. Press [Enter] when the desired setting is displayed.
SET STOP BIT
COMPLETED
7-16
TELECOPIER 7024 USER HANDBOOK
