REPORTS
Error message report (Failure report)
When the terminal is unable to complete a transmission as
requested, it automatically prints out this report to advise the
operator as to the nature of the error and recommend a course
olF action. If the document was transmitted from memory, a
partial page of the document will be added to the report.
The header contains the local name, local I.D. and current date
and time.
DESCRIPTION OF ERROR MESSAGE REPORT (FAILURE REPORT)
COLUMN TITLE COLUMN DESCRIPTION
ERROR MESSAGE One of three possible error messages: NO RESPONSE FROM
REMOTE MACHINE, RESEND BAD PAGES SEE ERROR MESSAGES or
PLEASE TRANSMIT AGAIN.
NO. Message counter for each day.
REMOTE STATION A name for the remote terminal, chosen from the following list (in
decreasing order of precedence):
•
Terminal name sent by the remote terminal
• Terminal name defined on the one touch dial, speed dial or
programmable one touch dial key on the local terminal.
• Terminal ID sent by the remote terminal
• Telephone number dialled
• G3, G2
MODE Resolution
Only G3 or G2 will be recorded depending on the ability of the
remote terminal.
START Date and time the activity started.
DURATION Communication duration time.
PAGES Number of pages transmitted or received.
RESULT Code indicating result of transmission:
NUMBER: Error code indicating reason for failure (See
Problem Solving Section)
*: ECM active
NOTE RELAY BC Relay send
B.C. Broadcast transmission
TXSMAIL Secure send
MANUAL Manual operation
MEMORY Memory received
POLLING Polling operation
MULTI Multi-polling operation
STOP Stop key is pressed.
SEND Send operation
TELECOPIER 7024 USER HANDBOOK 6-13
