lomponent descriptions
PREPARING THE MACHINE FOR OPERATION
This is a brief description of the function of each of the keys,
controls, tones and lights on the terminal.
1. Speaker volume control; Adjusts the volume of the speaker
and tones.
2. Telephone connections: Standard RJ-11C modular jacks.
Line
TELI;
TEL 2:
Handset :
Document guides:
Telephone line from wall jack.
RJ-11C modular jack for telephone
handset.
RJ-11C modular jack for a secondary
device (telephone or answering
machine) used with the terminal.
Provides voice capability.
Adjustable document guides for
varying widths.
5. Document input tray: Provides area to load original
documents.
6. Printer release button; Releases top cover to provide access
to printer area.
7. Power switch/cord: Controls power to the unit. Located
at the right rear corner of the
terminal.
8. Output tray extension; Provides an extended area for long
copies.
9. Imaging film indicator; Visual indication showing status of
imaging film.
10. Indicator (page length): A manual setting provided to
indicate the page length loaded in
the terminal.
11. Control panel: Contains buttons and lights for
interface with the terminal.
12. Paper tray assembly:
13. Scanner release button
14. Left hand cover:
Suppl ies paper to the termi naI.
Releases the scanner cover.
Provides access to clear a paper jam.
15. Document output tray: Provides area for completed copies
to accumulate.
TELECOPIER 7024 USER HANDBOOK 1-3
