PREPARING THE MACHINE FOR OPERATION
Control panel descriptions
Display; Two lines of information, each line provides 20
characters.
Wide scan: Use to automatically reduce the size of the pages
sent to a remote fax.
Menu; Use to select the appropriate menu and to store
information.
Resolution/Select: Use to select the scanning resolution,
functions and settings within a menu. Also use to display the
number of pending jobs and the amount of memory in use.
Enter: Use to select the features and save the selection of the
displayed feature.
Original/Clear: Use to select the contrast. Also use to clear
information in the display.
Voice request: Use to signal remote operator that voice
communication is desired; also use to enable on-hook dialling.
Manual receive; Use to select the receive mode.
Send confirm: Use to enable the print out of a Send Confirm
Report after a send operation.
Redial; Use to redial the last auto dialled telephone number.
T, ^ keys: Use to move the cursor when selecting the
characters for the local name and number.
- (Dash) Key: Use to insert a dash in telephone numbers and local
identification number to enhance legibility. Also instructs the
terminal to wait for a dial tone when pressed two times.
Tone: Use to change dialling system; tone or pulse.
Pause: Use to enter a pause in the dial sequence when manual
dialling or storing a one touch or speed dial telephone number.
Speed Dial: Use to activate dialling of stored speed dial
numbers.
Error LED: Indicates an error condition.
Copy: Use to select the copy function.
Stop; Use to stop an operation or reset the error LED.
Start: Use to begin an operation.
Terminal keypad: Use as a telephone dialling pad, to access
display menus, menu functions, and to create the dialling
directories.
One touch keys (01-24): Use to program telephone numbers for
one touch dialling of an individual terminal.
Multifunction keys (P1-P6): Use to program telephone numbers
as standard one touch keys and to program multi-step
operations for delayed send, delayed group send, relay send,
send secure mail, delayed polling and multi-polling as program
one touch keys. These six keys can have both the standard one
touch and the program one touch functions assigned at the same
time.
TELECOPIER 7024 USER HANDBOOK 1-5
