REPORTS
DESCRIPTION OF ACTIVITY REPORT
COLUMN TITLE COLUMN DESCRIPTION
NO. Transaction counter for each day
REMOTE STATION A name for the remote terminal, chosen from the
following list (in decreasing order of precedence):
• Terminal name sent by the remote terminal
• Terminal name defined on the One Touch Dial,
Speed Dial, or Program One Touch Dial key on the
local terminal
• Terminal ID sent by the remote terminal (telephone
number)
• Telephone number dialled
• G3, G2
MODE Resolution
Only G3 or G2 will be recorded depending on the ability
of the remote terminal.
START Starting time for transmission
DURATION Time elapsed between start and end of transmission
PAGES Number of transmitted or received pages
RESULT Status of transmission.
OK: Indicates successful completion of
operation.
ERROR CODE: Indicates reason for failure.
(See Problem Solving Section)
* Indicates ECM is active.
NOTE Comments on features used:
• RELAY BC; Relay send
• B.C.: Broadcast send
• TXSMAIL: Mailbox send
• MANUAL: Manual operation
• MEMORY: Receive to memory
• POLLING: Polling operation
• MULTI: Multi polling operation
• STOP: Stop key pressed
• SEND: Normal send operation
TELECOPIER 7024 USER HANDBOOK 6-3
