PREPARING THE MACHINE FOR OPERATION
Set terminal and handset dialling type
The telephone lines require either touch tone or pulse dialling
signals. If you are unsure of the dialling signals required by your
telephone system, call your telecommunication company for
assistance. The switch on the handset and the menu option on
the terminal must be set to meet the telephone system
requirements. Ensure the terminal menu and the handset switch
have the same dial option selected.
There are three dialling settings: TONE, 20PPS (pulse per second'
and 10PPS. The tone setting will satisfy the majority of the
telephone systems.
To set terminal dialling type (Menu 09, Feature 17)
1. Press [Menu].
l.SEND OPTIONSl
01-10
SELECT/ENTER
2. Press [0], [9].
9.USER SETTINGS
01-10
SELECT/ENTER
3. Press [Enter].
l.SET POLLED MODE
01-21
SELECT/ENTER
4. Press [1], [7].
17.SET DIALLING TYPE
01-21
SELECT/ENTER
5. Press [Enter].
DIALLING MODE:
TONE
SELECT/ENTER
6. Press [Select] to scroll through the dialling type settings:
TONE, 20PPS or 10PPS.
DIALLING MODE:
TONE
SELECT/ENTER
7. Press [Enter] when the desired setting is displayed.
SET DIALLING TYPE
COMPLETED
TELECOPIER 7024 USER HANDBOOK
1-13
