High-Speed Microcontroller User’s
Guide: Network Microcontroller
Supplement
81
Memory Control Register 2 (MCON2)
R = Unrestricted read, T = Timed-access write, -n = Value after reset
This register is not present on the DS80C41/411.
7 6 5 4 3 2 1 0
SFR D7h WPIF WPR2 WPR1 WPR0 WPE3 WPE2 WPE1 WPE0
RT-0 RT-0 RT-0 RT-0 RT-0 RT-0 RT-0 RT-0
WPIF
Bit 7
WPR2-0
Bits 6-4
Write-protected interrupt flag. This flag is set by hardware when an MOVX instruction attempts to write
to a write-protected memory area. Once set, this bit must be cleared by software.
Write-protected range bits 2-0. These bits specify the write-protection range when any write-protected
enable bits are set:
WPR2 WPR1 WPR0 PROTECTION RANGE(kB)
0 0 0 0–2
0 0 1 0–4
0 1 0 0–6
0 1 1 0–8
1 0 0 0–10
1 0 1 0–12
1 1 0 0–14
1 1 1 0–16
WPE3
Bit 3
WPE2
Bit 2
WPE1
Bit 1
WPE0
Bit 0
Write-protected enable 3. Setting the WPE3 to 1 enables write protection on the lower memory loca-
tions controlled by CE3 when PDCE3 (MCON.3) is set. Any MOVX write attempt to these locations sets
the WPIF bit and leaves the data unaltered. Clearing this bit to 0 disables the write protection. The pro-
tection range is specified by the WPR2-0 bits.
Write-protected enable 2. Setting the WPE2 to 1 enables write protection on the lower memory loca-
tions controlled by CE2 if PDCE2 in the MCON register is also set. Any MOVX write to these locations
sets the WPIF bit and no data is altered. Clearing this bit to 0 disables the write protection. The protec-
tion range is specified by the WPR2-0 bits.
Write-protected enable 1. Setting the WPE1 to 1 enables write protection on the lower memory loca-
tions controlled by
CE1 if PDCE1 in the MCON register is also set. Any MOVX write to these locations
sets the WPIF bit and no data is altered. Clearing this bit to 0 disables the write protection. The protec-
tion range is specified by the WPR2-0 bits.
Write-protected enable 0. Setting the WPE0 to 1 enables write protection on the lower memory loca-
tions controlled by CE0 if PDCE0 in the MCON register is also set. Any MOVX write to these locations
sets the WPIF bit and no data is altered. Clearing this bit to 0 disables the write protection. The protec-
tion range is specified by the WPR2-0 bits.
