Page 30: Timer 1 msb (th1)
High-Speed Microcontroller User’s
Guide: Network Microcontroller
Supplement
30
Timer 0 LSB (TL0)
Timer 1 LSB (TL1)
Timer 0 MSB (TH0)
Timer 1 MSB (TH1)
TL0.7–0
Bits 7–0
Timer 0 LSB. This register contains the least significant byte of timer 0.
TL1.7–0
Bits 7–0
Timer 1 LSB. This register contains the least significant byte of timer 1.
TH0.7–0
Bits 7–0
Timer 0 MSB. This register contains the most significant byte of timer 0.
TH1.7–0
Bits 7–0
Timer 1 MSB. This register contains the most significant byte of timer 1.
7
6
5
4
3
2
1
0
SFR 8Ah
TL0.7
TL0.6
TL0.5
TL0.4
TL0.3
TL0.2
TL0.1
TL0.0
RW-0
RW-0
RW-0
RW-0
RW-0
RW-0
RW-0
RW-0
R = Unrestricted read, W = Unrestricted write, -n = Value after reset
7
6
5
4
3
2
1
0
SFR 8Bh
TL1.7
TL1.6
TL1.5
TL1.4
TL1.3
TL1.2
TL1.1
TL1.0
RW-0
RW-0
RW-0
RW-0
RW-0
RW-0
RW-0
RW-0
R = Unrestricted read, W = Unrestricted write, -n = Value after reset
7
6
5
4
3
2
1
0
SFR 8Ch
TH0.7
TH0.6
TH0.5
TH0.4
TH0.3
TH0.2
TH0.1
TH0.0
RW-0
RW-0
RW-0
RW-0
RW-0
RW-0
RW-0
RW-0
R = Unrestricted read, W = Unrestricted write, -n = Value after reset
7
6
5
4
3
2
1
0
SFR 8Dh
TH1.7
TH1.6
TH1.5
TH1.4
TH1.3
TH1.2
TH1.1
TH1.0
RW-0
RW-0
RW-0
RW-0
RW-0
RW-0
RW-0
RW-0
R = Unrestricted read, W = Unrestricted write, -n = Value after reset
Maxim Integrated
