External Memory Access

The DS80C400 follows the memory interface convention established by the industry standard 80C32/80C52 but with many added

improvements. Most notably, the device incorporates a 24-bit addressing capability that directly supports up to 16MB of program mem-

ory and 4MB of data memory. Externally, the memory is accessed through a multiplexed or demultiplexed 22-bit address bus/8-bit data

bus and eight chip-enable signals (active during program memory access) or four peripheral-enable signals (active during data mem-

ory access). Multiplexed addressing mode mimics the traditional 8051 memory interface with the address MSB presented on port 2

and the address LSB and data multiplexed on port 0. The multiplexed mode requires an external latch to demultiplex the address LSB

and data. When the MUX pin is pulled high, the address LSB and data are demultiplexed with the address MSB presented on port 2,

the address LSB on port 7, and the data on port 0. The elimination of the demultiplexing latch removes a delay element in the memo-

ry timing and can, in some cases, allow the use of slower, less expensive memory devices. Table 6-2 illustrates the locations of the

external memory control signals.

Table 6-2. External Memory Addressing Pin Assignments

Each upper-order address line (A16–A21) and chip or peripheral enable is individually enabled by the P4CNT, P5CNT, and P6CNT reg-

isters. Enabling upper-order address lines increases the maximum size of the external memories that can be addressed, and enabling

chips or peripheral enables control the number of external memories that can be addressed. For example, if P4CNT.5-3 are set to 010b,

A17 and A16 are enabled (along with A15–A0), permitting each chip-enable access a maximum memory device size of 2

or 256kB.

Note that the desired chip-enable signals must be enabled in order to become active for a defined memory range.

The configurable program/code chip-enable (CEx) and MOVX chip-enable (PCEx) signals issued by the microcontroller are used when

accessing multiple external memory devices. External chip-enable lines are only required if more than one physical block of memory

are used. In the standard 8051 configuration, PSEN is used as the output enable for the program memory device, and RD and WR con-

trol the input or output functions of the data (SRAM) device. Typically, the chip enables of the program and data memory devices can

be connected to their active state if only one of each is used. To support a larger amount of memory, however, the microcontroller must

generate chip or data enables to select one of several memory devices. Tables 6-3 through 6-5 demonstrate how to enable various

combinations of high-order address lines and chip enables.

SIGNAL

MULTIPLEXED (MUX = 0)

DEMULTIPLEXED (MUX = 1)

A21

P6.5

A20

P6.4

A19

P4.7

A18

P4.6

A17

P4.5

A16

P4.4

A15–A8

P2.7–P2.0

ADDRESS

A7–A0

P0.7–P0.0

P7.7–P7.0

DATA

D7–D0

P0.7–P0.0

CE7

P6.3

CE6

P6.2

CE5

P6.1

CE4

P6.0

CE3

P4.3

CE2

P4.2

CE1

P4.1

CHIP ENABLES

CE0

P4.0

PCE2

P5.7

PCE1

P5.6

PCE0

P5.5

PERIPHERAL

CHIP ENABLES

—

P5.4
