Special-Function Register Map
Special-Function Register Location
High-Speed Microcontroller User’s
Guide: Network Microcontroller
Supplement
18
START
ADDRESS
SFR NAMES
END
ADDRESS
80 P4 SP DPL DPH DPL1 DPH1 DPS PCON 87
88 TCON TMOD TL0 TL1 TH0 TH1 CKCON 8F
90 P1 EXIF P4CNT DPX DPX1 C0RMS0 C0RMS1 97
98 SCON0 SBUF0 ESP AP ACON C0TMA0 C0TMA1 9F
A0 P2 P5 P5CNT C0C C0S C0IR C0TE C0RE A7
A8 IE SADDR0 SADDR1 C0M1C C0M2C C0M3C C0M4C C0M5C AF
B0 P3 P6 P6CNT C0M6C C0M7C C0M8C C0M9C C0M10C B7
B8 IP SADEN0 SADEN1 C0M11C C0M12C C0M13C C0M14C C0M15C BF
C0 SCON1 SBUF1 PMR STATUS MCON TA C7
C8 T2CON T2MOD RCAP2L RCAP2H TL2 TH2 COR CF
D0 PSW MCNT0 MCNT1 MA MB MC MCON1 MCON2 D7
D8 WDCON SADDR2 BPA1 BPA2 BPA3 DF
E0 ACC OCAD CSRD CSRA EBS BCUD BCUC E7
E8 EIE MXAX DPX2 DPX3 OWMAD OWMDR EF
F0 B SADEN2 DPL2 DPH2 DPL3 DPH3 DPS1 STATUS1 F7
F8 EIP P7 TL3 TH3 T3CM SCON2 SBUF2 FF
REGISTER BIT 7 BIT 6 BIT 5 BIT 4 BIT 3 BIT 2 BIT 1 BIT 0 ADDRESS
P4 80h
SP 81h
DPL 82h
DPH 83h
DPL1 84h
DPH1 85h
DPS ID1 ID0 TSL AID SEL1 — — SEL 86h
PCON SMOD_0 SMOD0 OFDF OFDE GF1 GF0 STOP IDLE 87h
TCON TF1 TR1 TF0 TR0 IE1 IT1 IE0 IT0 88h
TMOD GATE C/ T M1 M0 GATE C/T M1 M0 89h
TL0 8Ah
TL1 8Bh
TH0 8Ch
TH1 8Dh
CKCON WD1 WD0 T2M T1M T0M MD2 MD1 MD0 8Eh
P1 90h
EXIF IE5 IE4 IE3 IE2 CKRY RGMD RGSL BGS 91h
P4CNT — — P4CNT.5 P4CNT.4 P4CNT.3 P4CNT.2 P4CNT.1 P4CNT.0 92h
DPX 93h
DPX1 95h
C0RMS0* 96h
C0RMS1* 97h
