High-Speed Microcontroller User’s
Guide: Network Microcontroller
Supplement
64
CAN 0 Message Center 7 Control Register (C0M7C)
CAN 0 Message Center 8 Control Register (C0M8C)
CAN 0 Message Center 9 Control Register (C0M9C)
CAN 0 Message Center 10 Control Register (C0M10C)
7
6
5
4
3
2
1
0
SFR B4h
MSRDY
ETI
ERI
INTRQ
EXTRQ
MTRQ
ROW/TIH
DTUP
RW-0
RW-0
RW-0
RW-0
RC-0
R*-0
R*-0
R*-0
R = Unrestricted read, C = Clear only, * = See description, -n = Value after reset
This SFR is not present on the DS80C411.
7
6
5
4
3
2
1
0
SFR B4h
MSRDY
ETI
ERI
INTRQ
EXTRQ
MTRQ
ROW/TIH
DTUP
RW-0
RW-0
RW-0
RW-0
RC-0
R*-0
R*-0
R*-0
R = Unrestricted read, C = Clear only, * = See description, -n = Value after reset
This SFR is not present on the DS80C411.
7
6
5
4
3
2
1
0
SFR B5h
MSRDY
ETI
ERI
INTRQ
EXTRQ
MTRQ
ROW/TIH
DTUP
RW-0
RW-0
RW-0
RW-0
RC-0
R*-0
R*-0
R*-0
R = Unrestricted read, C = Clear only, * = See description, -n = Value after reset
This SFR is not present on the DS80C411.
7
6
5
4
3
2
1
0
SFR B6h
MSRDY
ETI
ERI
INTRQ
EXTRQ
MTRQ
ROW/TIH
DTUP
RW-0
RW-0
RW-0
RW-0
RC-0
R*-0
R*-0
R*-0
R = Unrestricted read, C = Clear only, * = See description, -n = Value after reset
This SFR is not present on the DS80C411.
C0M7C
Bits 7–0
Operation of the bits in this register are identical to those found in the CAN 0 message 1 control regis-
ter (C0M1C: ABh). Consult the description of that register for more information.
C0M8C
Bits 7–0
Operation of the bits in this register are identical to those found in the CAN 0 message 1 control regis-
ter (C0M1C: ABh). Consult the description of that register for more information.
C0M9C
Bits 7–0
Operation of the bits in this register are identical to those found in the CAN 0 message 1 control regis-
ter (C0M1C: ABh). Consult the description of that register for more information.
C0M10C
Bits 7–0
Operation of the bits in this register are identical to those found in the CAN 0 message 1 control regis-
ter (C0M1C: ABh). Consult the description of that register for more information.
