Special-Function Register Reset Values (continued)
High-Speed Microcontroller User’s
Guide: Network Microcontroller
Supplement
22
REGISTER BIT 7 BIT 6 BIT 5 BIT 4 BIT 3 BIT 2 BIT 1 BIT 0 ADDRESS
IP 1 0 0 0 0 0 0 0 B8h
SADEN0 0 0 0 0 0 0 0 0 B9h
SADEN1 0 0 0 0 0 0 0 0 BAh
C0M11C* 0 0 0 0 0 0 0 0 BBh
C0M12C* 0 0 0 0 0 0 0 0 BCh
C0M13C* 0 0 0 0 0 0 0 0 BDh
C0M14C* 0 0 0 0 0 0 0 0 BEh
C0M15C* 0 0 0 0 0 0 0 0 BFh
SCON1 0 0 0 0 0 0 0 0 C0h
SBUF1 0 0 0 0 0 0 0 0 C1h
PMR 1 0 0 0 0 0 1 1 C4h
STATUS 0 0 0 1 0 0 0 0 C5h
MCON* 0 0 0 1 0 0 0 0 C6h
TA 1 1 1 1 1 1 1 1 C7h
T2CON 0 0 0 0 0 0 0 0 C8h
T2MOD 1 1 0 0 0 1 0 0 C9h
RCAP2L 0 0 0 0 0 0 0 0 CAh
RCAP2H 0 0 0 0 0 0 0 0 CBh
TL2 0 0 0 0 0 0 0 0 CCh
TH2 0 0 0 0 0 0 0 0 CDh
COR* 0 1 1 0 0 0 0 0 CEh
PSW 0 0 0 0 0 0 0 0 D0h
MCNT0 0 0 0 0 0 0 0 0 D1h
MCNT1 0 0 0 0 1 1 1 1 D2h
MA 0 0 0 0 0 0 0 0 D3h
MB 0 0 0 0 0 0 0 0 D4h
MC 0 0 0 0 0 0 0 0 D5h
MCON1 SPECIAL SPECIAL 1 1 0 0 0 0 D6h
MCON2 0 0 0 0 0 0 0 0 D7h
WDCON 0 SPECIAL 0 SPECIAL 0 SPECIAL SPECIAL 0 D8h
SADDR2 0 0 0 0 0 0 0 0 D9h
BPA1 0 0 0 0 0 0 0 0 DAh
BPA2 0 0 0 0 0 0 0 0 DBh
BPA3 0 0 0 0 0 0 0 0 DCh
ACC 0 0 0 0 0 0 0 0 E0h
OCAD 0 0 0 0 0 0 0 0 E1h
CSRD 0 0 0 0 0 0 0 0 E3h
CSRA 0 0 0 0 0 0 0 0 E4h
EBS 0 1 1 0 0 0 0 0 E5h
BCUD 0 0 0 0 0 0 0 0 E6h
BCUC 0 0 0 0 0 0 0 0 E7h
EIE* 0 0 0 0 0 0 0 0 E8h
MXAX 0 0 0 0 0 0 0 0 EAh
DPX2 0 0 0 0 0 0 0 0 EBh
DPX3 0 0 0 0 0 0 0 0 EDh
OWMAD 0 0 0 0 0 1 1 1 EEh
OWMDR 0 0 0 0 0 0 0 0 EFh
B 0 0 0 0 0 0 0 0 F0h
