Functional Diagrams

Pin Configurations appear at end of data sheet.
Functional Diagrams continued at end of data sheet.

UCSP is a trademark of Maxim Integrated Products, Inc.

For pricing, delivery, and ordering information, please contact Maxim Direct
at 1-888-629-4642, or visit Maxim’s website at www.maximintegrated.com.

x3

SERIAL

UARTs

COMMUNICATE WITH

NEW AND LEGACY

EQUIPMENT

REMOTE MONITORING

AND CONTROL

VIA THE NETWORK

8051

µC

WITH TCP/IPv4/6

NETWORK STACK IN

ROM

10/100

ETHERNET

MAC

DS80C400/DS80C410/DS80C411

NETWORKED MICROCONTROLLER

Rev: 12; 9/08

HIGH-SPEED MICROCONTROLLER USER’S GUIDE:

NETWORK MICROCONTROLLER SUPPLEMENT

This document is provided as a supplement to the High-Speed Microcontroller User’s Guide, covering new or modified features spe-

cific to the DS80C400/DS80C410/DS80C411. This document must be used in conjunction with the High-Speed

Microcontroller User’s Guide, available from Maxim. Addenda are arranged by section number, which correspond to sec-

tions in the High-Speed Microcontroller User’s Guide.

Unless otherwise specified, the references to the DS80C400 and its features also apply to the DS80C410 and DS80C411. Exceptions

include differences in the amount of internal memory and the inclusion/exclusion of the CAN module.

The following additions and changes, with respect to the High-Speed Microcontroller User’s Guide, are contained in this document.

This document is a work in progress, and updates/additions are added when available.
